Radonix X4 Expander increases the axis capacity of your CNC machines, allowing you to operate more motors simultaneously. Specifically designed for gold and jewelry CNC machining, this module enables you to expand your systems up to 24 axes by utilizing Radonix’s 6-axis control cards.
- 2-Year Warranty
- 10-Year After-Sales Service
- 24/7 Support
| Feature | Description |
|---|---|
| Axis Expansion | Up to 1 to 4 |
| Input Pulse Type | Line Drive |
| Output Pulse Type | Line Drive |
| Digital Input | NPN Isolated Input |
What is X4?
The Radonix X4 Expander is designed for gold and jewelry processing CNC machines. It can take standard step/direction signals for a single axis and distribute them to four separate motor drivers, enabling synchronized operation of motors in special configurations such as multiple Z-axes or dual X-axes. This feature is particularly important for complex jewelry designs requiring multiple processing heads and precise gold engraving tasks.
Technical Specifications
Input Signals: Standard step/direction signals received from the main control device.
Signal Replication: The X4 Expander replicates incoming signals across four separate channels.
Motor Drivers: Each channel can be connected to independent motor drivers. This allows multiple motors to operate simultaneously with the same precision and synchronization.
Seamless Integration: Equipped with NPN isolated inputs and line driver outputs. This technology minimizes electromagnetic interference and ensures highly precise and reliable movements.
Expandable Axis Capacity: Each axis can be expanded up to four times with the X4 module. This allows for a total capacity of 16 axes, making it ideal for complex gold processing applications that require multiple axes.
